Convoy M21H 21700 flashlight
Convoy M21H 21700 flashlight
WISHLIST
Quantity
Detail
Customer Reviews
Parameters:
Material: aluminum alloy
Low voltage warning: yes
Reverse polarity protection: yes
Lens Type: ar-coated glass lens ,3degree TIR for SFT40, 12 degree TIR for other LED modes
Switch position: side
Mode memory: yes
Tail stand: yes
Driver output :
6V 5A for XHP70.2,XHP70.3 Hi
12V 2.5A for GT FC40
3V 8A for GT red/green/blue light
3V 8A for GT red/green/blue light
Flux:
XHP70.2,XHP70.3 Hi R70--- 4000LM
XHP70.3 Hi R9050---3000LM
GT FC40 --- 2500LM
Maximum charging current: 2A
Battery charger includes: not included
Battery type required: 1*21700 standard battery
Number of batteries required: 1
Size: Head/body/tail diameter: 40mm/27mm/28.5mm
length: 130.8mm
Product weight: 132g
Mode operation instructions:
1.click the button ——> flashlight is turned on with last brightness ——> press the button,brightness ramping up ——> release and press the button again,brightness ramping down
2.flashlight off, press the button ——> moonlight mode (0.2%) [This brightness will not be remembered]
3.flashlight on or off, 2-click the button ——> turbo 100%
4.flashlight off,3-click the button ——> strobe
5.flashlight off,4-click the button ——> tactical mode, only 100% ,4-click the button again to quit tactical mode.
6.flashlight off,5-click the button ——> voltage detection (* means "flash" , *** pause ******* means 3.7V, )
7.flashlight off,6-click the button ——> normal ramping mode switch to 4modes 1%-10%-40%-100%
8.flashlight off,10-click the button ——> Lock mode,The flashlight will flash once under any operation, which means the flashlight is locked.10-click the button again to quit lock mode,Please note that this is the only way to unlock.
The flashlight has low voltage protection and temperature control protection.
